Reyee XG-SFP-LR-SM1310Reyee XG-SFP-LR-SM1310

Warranty

1 Year

Brand

Ruijie Reyee

Model

XG-SFP-LR-SM1310

Product Type

10G SFP+ Optical Transceiver

Standard

10GBASE-LR, IEEE 802.3ae

Data Rate

10.3125 Gbps

Wavelength

1310 nm

Fiber Type

Single-Mode Fiber (SMF)

Reach

Up to 10 km

Connector

Duplex LC

Fiber End Face

UPC

Transmitter

DFB Laser

Receiver

PIN

TX Optical Power

-8.2 to 0.5 dBm

RX Sensitivity

< -12.6 dBm

DOM/DDM

Supported

Power Consumption

≤ 1.5 W

BER

1×10⁻¹²

Operating Temperature

0°C to 70°C

Storage Temperature

-40°C to 85°C

Hot-Pluggable

Yes

Compliance

SFP+ MSA, SFF-8431, RoHS

Application

Data Center, Campus Network, Switch/Router 10G Uplink

Brand: Ruijie Reyee Model: XG-SFP-LR-SM1310 Product Type: 10G SFP+ Optical Transceiver Standard: 10GBASE-LR, IEEE 802.3ae Data Rate: 10.3125 Gbps Wavelength: 1310 nm Fiber Type: Single-Mode Fiber (SMF) Reach: Up to 10 km Connector: Duplex LC Fiber End Face: UPC Transmitter: DFB Laser Receiver: PIN TX Optical Power: -8.2 to 0.5 dBm RX Sensitivity: < -12.6 dBm DOM/DDM: Supported Power Consumption: ≤ 1.5 W BER: 1×10⁻¹² Operating Temperature: 0°C to 70°C Storage Temperature: -40°C to 85°C Hot-Pluggable: Yes Compliance: SFP+ MSA, SFF-8431, RoHS Application: Data Center, Campus Network, Switch/Router 10G Uplink

Need a different configuration, quantity pricing or a lead-time estimate? Add this product to your quote list and tell us what you need — our engineers respond within one business day.
